When trying to figure out why the internet is slow, it can be hard to learn exactly which device on the network is eating up all the bandwidth. Many solutions to this problem require software to be installed on every device to be monitored. Instead, I tried to build a custom Raspberry Pi network monitor.

This post will show you how to monitor all internet traffic for every device on your network, without buying any specialty hardware.

This open-source solution has been used by readers of this site for monitoring family internet usage, LAN parties, and more.

This project came about when retrofitting our cabin in the woods to a smart-home. There internet providers out here advertise about 30 Mbps (down) and 2 Mbps (up). This isn’t much to work with. Plus, we have many home-made IOT devices scattered around the house. So… who knows where the traffic is going?

My goal was to not require any special software, yet monitor the internet traffic for every network device.

Ideally, I also wanted to create a beautiful Grafana dashboard. This would let me see what sites the devices were contacting with the Raspberry Pi network monitor.

It seemed like a couple others on Reddit were also interested in a solution to this problem, so I decided to give it a try. The result was an open-source Python script / Docker container, meant to be run on a Raspberry Pi, that exports data to Prometheus. While I set up a Raspberry Pi, the code should run on any Linux distribution. There are Docker images for both arm and amd.

Skip to the end of this post for source code & installation.

But first, let’s consider the different ways to monitor traffic on a home network…

Internet Traffic Monitor: Approaches

Based upon experience and some research, these are the possibilities I came up with:

  1. Pi as a router
    The obvious way to monitor network traffic. The Raspberry Pi sits between the devices to be tracked and the internet (e.g., acting as a router or access point). Unfortunately, this can slow down the network, which causes many to avoid the approach (see the next section).
  2. Router reporting
    Some modern routers provide features along these lines. But generally custom firmware is required.
  3. Device reporting
    The standard protocol for this is SNMP, which will rely upon device side installations to self-report. It integrates well with Prometheus/Grafana though.
  4. Packet sniffing
    You could theoretically monitor the wireless traffic (if all you care about is WiFi). This is the same concept that allows attackers to sniff traffic on a WiFi network.

Each of these has its drawbacks. I did not want to buy a new router, so router reporting was not an option. I could not install the necessary software on all the IOT devices, which prevents device reporting. And packet sniffing is an interesting idea, but I wanted to be able to handle wired as well as wireless traffic.

This left only one approach: set up a Raspberry Pi network monitor.

Raspberry Pi Home Network Monitor

If all internet traffic is going to pass through a device, it is good to use caution.

The first concern is that of security. I won’t say too much about that here, except to mention that a firewall of some kind is a good idea. I went with Uncomplicated Fire Wall (ufw) because it is, well, uncomplicated.

A less obvious concern is that of speed. When traffic passes through a router/switch, the primary bottleneck is the ethernet hardware. In other words, the CPU and RAM are not as important as in other cases. This was something of a problem with the Raspberry Pi 3B (and lower). However, the Raspberry Pi model 4 has an upgraded on-board 1000 Mbps eth0 port.

Make sure that the ethernet hardware meets the needs.

Failure to do so could slow down the entire network!

With that in mind, here is the exact list of parts I used.

If you're new to Raspberry Pi, the popular CanaKits are a great place to start. I prefer to buy the Raspberry Pi 4, power adapter, micro SD cards, and heatsinks separately. Not only is this cheaper, but it reduces e-waste.

The following are affiliate links to other parts I used in this project. I never link to a product that I have not personally used.

With the parts in-hand, I drew up this Raspberry Pi 4 router design:

raspberry pi network monitor traffic diagram
This router to switch connection diagram shows how we monitor network traffic.

If you’re using the above parts list…

Some important points:

  • The WiFi router is in Bridge mode. This means that eth0 must act as the DHCP server (assign IP addresses to the network).
  • Traffic between devices on the network will not flow through the Raspberry Pi. See the Performance Tests, below.
  • This means that the Pi is only a bottleneck for internet traffic. With 1000 Mbps hardware and an ISP that only provides 30 Mbps, we won’t be hitting this limit any time soon.

There are many ways to set up the eth1 <> eth0 connection. You could configure this using internet bonding software. This would let you add another internet connection (eth2) to make the internet connection even faster. For a more complete DIY Raspbery Pi router solution:

Alternate Design

If you’re not using the Raspberry Pi as a router, this section is for you.

The traffic must flow through the device.

You must have two network interfaces over which the traffic you wish to capture passes.

You could flip the WiFi router and Rasbperry Pi network monitor from the above diagram. This approach can work better if you prefer to not use the Raspberry Pi as a router:

  • The WiFi router connects to the modem/internet (not in bridge mode).
  • The Raspberry Pi connects to the internet through the WiFi router.
  • The Raspberry Pi should have a static IP assigned by your WiFi router (see its documentation).

However, it does have one major disadvantage: the WiFi traffic (going to the router) will not be monitored. But the major advantage is: if you ever want to remove the Raspberry Pi network monitor, just plug the WiFi router directly in to the switch.

You could also run a separate DHCP server on the WAN side of the Raspberry Pi. In this case, again, the Pi is not the router. However, if the two network interfaces are bridges, then the traffic is flowing through the Pi.

No matter the design, the device acting as the router connects to the internet, and the device connected to the switch is in bridge mode. In other words, you must manually bridge the two interfaces on the Raspberry Pi. Therefore, the Pi’s eth0 is able to see traffic passing in and out of the LAN.

Performance Tests

After implementing the Pi as a router, I saw no decrease in speed for intra-network traffic. This was tested with iperf3. It showed:

  • ~910 Mbits/sec for two computers connected via a physical switch.
  • ~180 Mbits/sec when separated by a long WiFi hop.
Screen Shot 2020 04 04 at 8.09.44 AM
Our ISP only advertises 30 Mbps! We never saw speeds above that before implementing the Pi as a router.

Shockingly, I saw improved external (internet) speeds with the Raspberry Pi network monitor. I already had Node RED running a speedtest every 5 minutes and recording the data to Home Assistant + Prometheus. When using the CenturyLink provided DSL router, I rarely saw speeds above 25 Mbps (down). Now we consistently seeing speeds in the ~33 Mbps range. This is likely because the Raspberry Pi is using pppoeconf to establish the DSL connection directly, and it does a better job managing this connection than the modem provided by the ISP.

Accuracy Tests

Now, to test the accuracy of the Raspberry Pi network monitor.

Using Prometheus for throughput/bandwidth will not be perfectly accurate on a short time scale. This is due to the way a rate is averaged over an interval. However, by downloading a large file, I was able to compare the reported download speed from Chrome with that of the traffic graph:

raspberry pi network monitor dashboard with Grafana
The ~2.4 MB/s reported by Chrome matches the rate reported by Grafana, albeit with some reporting-time lag.

In addition, the total download size matched that reported by Chrome:

Raspberry Pi network monitor dashboard downloads by server
Note: this graph is computed via an increase on a counter. If the monitoring software gets reset, the values will not be accurate. If anybody knows a better way to do this with PromQL, please do let me know.

Screenshots, Installation, & Source Code

This project is open-source. It is available as a Python script or Docker image.

Find the code & detailed documentation for the Raspberry Pi Network Monitor in the network-traffic-metrics Github repository.

The most important part of the configuration is setting up the tcpdump filters. For example, the following will restrict the captured traffic to that which flows in or out of the 192.168.0.0/24 subnet:

(src net 192.168.0.0/24 and not dst net 192.168.0.0/24) or (dst net 192.168.0.0/24 and not src net 192.168.0.0/24)

For more help setting up the filters, check out this blog post by Daniel Miessler on isolating traffic with tcpdump. If you’re having trouble with anything else, please comment below or contact me directly.

Raspberry Pi Network Monitor Configuration File

I’ll try to give copy and paste instructions below. However, as I mentioned in the “Using the Pi as a Router” section, some of these steps may be highly individual. The bridge steps, in particular, can depend on the exact Linux version you have installed. I’ll assume you…

  • Have eth0 (LAN) and eth1 (WAN) on your device.
  • Pi will reside at 192.168.0.1, either as the router or as a pass-through (alternate design).
  • IP addresses will be handed out on the 192.168.0.0/24 subnet.
  • You want to use Google’s DNS servers (8.8.8.8 and 8.8.4.4)
  • Running Raspbian Buster.

1. Build or Configure the Router

If you wist to use the Raspberry Pi as the router (first option), please see this article. If you wish for the WiFi router to connect to the internet (alternate design), follows its instruction manual to assign the Pi a static IP address (192.168.0.1 in this example).

2. Run the Raspberry Pi network monitor script

If you’re comfortable with it, a Docker/Kubernetes install may be easier than these manual steps. Otherwise…

sudo apt-get install git python3-pip tcpdump
sudo pip3 install argparse prometheus_client
git clone https://github.com/zaneclaes/network-traffic-metrics.git
cd ./network-traffic-metrics
sudo python3 ./network-traffic-metrics.py "(src net 192.168.0.0/24 and not dst net 192.168.0.0/24) or (dst net 192.168.0.0/24 and not src net 192.168.0.0/24)"

Open your web browser to http://192.168.0.1:8000/metrics to see the counters being exported for Prometheus. Verify that you’re seeing data that seems to match the traffic on your network. It may be hard to read, but upon refreshing the page you should see more lines added as people connect to different sites.

You can change several options by passing certain command-line flags to the script. For example, the script assumes that you want to listen to the eth0 interface. If you aliased this to the name lan, per the Raspberry Pi router guide, you could add the --interface lan flag. Or, the --port 80 flag would change from listening on port 8000 to port 80. Note that all the configuration variables may also be set via environment variables, like NTM_INTERFACE.

To make the script start on reboot, type sudo crontab -e and add:

@reboot python3 /home/pi/network-traffic-metrics/network-traffic-metrics.py "(src net 192.168.0.0/24 and not dst net 192.168.0.0/24) or (dst net 192.168.0.0/24 and not src net 192.168.0.0/24)" &

Alternatively, you could create a systemd service (generally preferred).

3. Install Prometheus

Prometheus and Grafana can be run anywhere on the same network. I’d recommend not running them on the same device doing the metric exporting. This prevents slowing down the machine. The following instructions are copied more or less exactly from the official Prometheus docs:

Download the latest release of Prometheus for your platform, then extract and run it:

tar xvfz prometheus-*.tar.gz
cd prometheus-*

Edit prometheus.yml (which should have been included in the download). See the two comments in this sample file. In particular, make sure that the last line matches the IP/port of the device running the metrics script from the last step.

global:
  scrape_interval:     15s # How frequently to report
  external_labels:
    monitor: 'network-traffic-metrics'

scrape_configs:
  - job_name: 'network-traffic-metrics'
    static_configs:
      - targets: ['192.168.0.1:8000'] # The Network Traffic Metrics IP/port

Run Prometheus: ./prometheus --config.file=prometheus.yml

Check that you can access Prometheus: localhost:9090/metrics (or wherever it is located).

4. Install Grafana

Again, the official docs are a good place to start (these are copied fairly directly):

sudo apt-get install -y apt-transport-https
sudo apt-get install -y software-properties-common wget
wget -q -O - https://packages.grafana.com/gpg.key | sudo apt-key add -
echo "deb https://packages.grafana.com/oss/deb stable main" | sudo tee -a /etc/apt/sources.list.d/grafana.list
sudo apt-get update
sudo apt-get install grafana

Open up http://localhost:3000/ to find Grafana. Add Prometheus as a data source:

  1. Open the side menu by clicking the Grafana icon in the top header.
  2. In the side menu under the Dashboards link you should find a link named Data Sources.
  3. Click the + Add data source button in the top header.
  4. Select Prometheus from the Type dropdown.
Internet traffic monitor data in Prometheus and Grafana
Verifying that Grafana can see the Prometheus data.

The default options should match your installation from above. If you’ve used containers or otherwise installed Prometheus differently, you will need to use the appropriate URL for the Prometheus server. For example, I used the URL http://prometheus-server with a Kubernetes helm deployment. If your data source is configured correctly, you should now be able to use the Explore section to see the data in Prometheus.

You could fiddle with this yourself and create a dashboard to your liking. Or, you could use my Raspberry Pi network monitor dashboard. Grafana has instructions for importing dashboards. In short, you use the + button on the left to Import dashboard 12619 (or the JSON file).

Import the internet traffic monitor dashboard.
Importing the dashboard from GrafanaLabs.

You should now have a working Raspberry Pi network monitor that can be accessed from Grafana. The only thing left to do is make sure you have the filters set correctly. When you open the dashboard, at the top of the screen, are the settings which configure what data are shown:

  • LocalIPs: the IP addresses on your LAN to show.
  • Services: e.g., http, https
  • Protos: e.g., tcp, udp
  • ExcludedServers: regex for servers (outside your network) to hide.

You should verify that your local IPs show up in the dropdown, and that you have not excluded any data you might want to be visualizing. For example, I intentionally filter speedtests and similar such traffic, as they add noise to the data:

Filtering traffic in the grafana dashboard

If your IP addresses are not showing up there, it is likely the case that the IP addresses on your local network do not conform to local subnet ranges. To fix this, open up the dashboard settings and look at the LocalIP variable’s regex. This regex filters all possible values, showing you the values which meet the regex at the bottom of the screen. You’ll need to modify the regex so that the IP addresses on your network show up in the “Preview of Values:”

Editing grafana dashboard network traffic filters.
The regex determines which values are considered “local” IP addresses.
